  • Product Item : Conical Tapered pole
  • Category: Lighting Pole
  • Pole design;BS EN 40
  • Material:BS EN 10025 S275 / JIS G3101 SS400
  • Welding:BS 5135
  • Galvanizing:BS 729 / ISO 1461
  • Product description:Conical Tapered pole Height from 6m to 12m Flange mounted or planted type Variable arm length from 0.125m to 3.0m with single or double arm type Variable spigot size from 35mm to 60mm.
  • Order online

Details

Hot dip galvanized Q235 steel with epoxy painted, no rust, no fade,no cracking or peeling in 30 years more.

Material Q235 sheet
Pole Height 3-12M
Wall thickness 3-5 mm
Diameter 60-300mm
Flange 20-600mm
Arm type single&double 1-3m
Surface treatment Galvanization & Painted
Painting expoy resin powder painted
Pole's shape
circle reducing
Wind resistance
30m/s
Material
Q235 Steel
Color
RAL color
Standard
DIN EN ISO
Grade
Q235 (default); or Q345, SUS201, SUS304 (if required)
Maintenance windows
1  pc with earthing unit inside
Foundation bolts
M24*950 L or J type (if required); price is excluded
No.s of bolts holes in flange plate
4 No.s of oval holes easily for aligement;

Galvanized steel tapered octagonal solar street light pole 8m design
Packing & Delivery

Package Methods:

Bulb pack (default); or woven bags or Packing blanket for optional; woven bags for metal fixings.

Shipping Methods:

Container by sea or land transportation.

Galvanized steel tapered octagonal solar street light pole 8m design
